Performance
| Motherboard form factor |
Mini ITX |
| Motherboard chipset family |
Intel |
| Component for |
Nettop |
| Cooling type |
Passive |
Memory
| Supported memory clock speeds |
1333, 1600 MHz |
| Supported memory types |
DDR3-SDRAM |
| Memory slots type |
DIMM |
| Number of memory slots |
2 |
| Maximum internal memory |
16 GB |
Internal I/O
| mSATA ports quantity |
1 |
| USB 2.0 connectors |
2 |
| ATX Power connector (24-pin) |
Y |
| USB 3.0 (3.1 Gen 1) connectors |
1 |
| Number of SATA III connectors |
4 |
| Azalia Digital Header (ADH) connector |
1 |
| Number of COM connectors |
1 |
| Number of chassis fan connectors |
2 |
| Front panel audio connector |
Y |
Graphics
| DirectX version |
11.1 |
| Graphics adapter family |
Intel |
| Discrete graphics support |
Y |
| HDCP |
Y |
Back panel I/O ports
| WiFi-AP antenna jack |
2 |
| S/PDIF out port |
Y |
| DVI-I ports quantity |
1 |
| DisplayPorts quantity |
1 |
| USB 3.0 (3.1 Gen 1) Type-A ports quantity |
4 |
| HDMI ports quantity |
1 |
Other features
| Number of processors supported |
1 |
Networking
| Bluetooth version |
4.0 |
| Wi-Fi |
Y |
| Bluetooth |
Y |
Expansion slots
| PCI Express x16 slots |
1 |
| PCI Express configurations |
1x16 |
| Mini PCI Express slots (full) |
1 |
Processor special features
| Intel® Clear Video HD Technology (Intel® CVT HD) |
Y |
Additionally
| Chipset |
Intel H87 |
| Intel HD Audio Technology |
Y |
| Количество слотов PCI Express |
2 |
| Dual-link DVI |
Y |
| Ethernet LAN connection |
Y |
| Ethernet LAN (RJ-45) ports quantity |
2 |
H87-ITX, LGA 1150, H87 Express, 2x DIMM, PCI Express 3.0, HDMI 1.4a, DP, DVI, Mini-ITX
Embrace the latest high-performance 4th Generation Intel Core processors with the ZOTAC H87-ITX WiFi mainboard. The ZOTAC H87-ITX WiFi incorporates all the features and performance enthusiasts demand from a tower desktop PC into a miniature mini-ITX form factor that is a fraction of the size without sacrificing expansion or connectivity.
Intel Smart Response technology enables the ZOTAC H87-ITX WiFi to harness the performance of solid-state storage and high capacity of hard drives to fuse into a single storage volume that offers the best of both worlds. Dual Gigabit Ethernet, 802.11n WiFi and Bluetooth 4.0 technology ensures the ZOTAC H87-ITX WiFi offers lightning-fast networking performance via wires or wireless.
