Networking
| Wi-Fi |
N |
| Supported network protocols |
IP, TCP, UDP, DHCP, Telnet, HTTP, PPPOE, NTP, SNMP |
| Ethernet LAN data rates |
10, 100 Mbit/s |
Technical details
| PTZ control (Pan/Tilt/Zoom) |
Y |
| ITU-supported standards |
T H.323 |
Audio
| Automatic gain control |
Y |
| Audio error concealment |
Y |
Ports & interfaces
| Component video (YPbPr/YCbCr) in |
1 |
| DVI-I ports quantity |
1 |
| Microphone in |
Y |
| AC (power) in |
Y |
| HDMI ports quantity |
3 |
| Phono inputs (RCA) |
2 |
Packaging content
| Handheld remote control |
Y |
| Microphone included |
Y |
Camera
| Focus adjustment |
Auto |
| Sensor type |
CMOS |
| Aperture range (F-F) |
1.8 - 2.2 |
Additionally
| Ethernet LAN connection |
Y |
| RS-232 port |
2 |
| Ethernet LAN (RJ-45) ports quantity |
2 |
HD Video Conference Terminal, up to 1440×900(WXGA+), Live Video up to 1080p 30fps, IP, TCP, UDP, DHCP, Telnet, HTTP, PPPOE, NTP, SNMP
Superior Visual Communication Experience
The T700S 2M enables the user to simultaneously send one 720p30 HD video stream and one XGA/WXGA content stream for data sharing. With HD video resolution and hi-fidelity audio support, the T700S 2M delivers a high quality and uncompromised videoconferencing experience.
Easy Deployment
The T700S 2M promises to be simple enough to install without any professional help. With an easy-to-use, graphically driven menu system, the terminal is very simple to operate and maintain. Easy deployment ensures that the T700S 2M video conferencing system can be used effectively in any type of meeting rooms.
Intelligent Network Features
In order to ensure the maximum video experience across challenging and disparate customer network environments, the T700 2M can automatically and dynamically adapt to network conditions using features such as FEC, and QOS which guarantees the best quality video and audio at up to 10% packet loss.
