Auto channel search | Y |
---|---|
Analog signal format system | PAL, PAL D, PAL DK, PAL I, PAL L, PAL M, SECAM |
Attenuator setting range | 0 - 60 dB |
Frequency range | 5 - 2150 MHz |
Satellite Channel Router (SatCR) compatible | Y |
Digital Satellite Equipment Control (DiSEqC) | 1.2 |
Input symbol rate | 45 Ms/s |
Modulation | COFDM, 16-QAM, 64-QAM, 8PSK, QPSK |
FM band range | 88 - 108 MHz |
Input impedance | 75 Ω |
Memory capacity (programs) | 1000 |
Resolution filter | 300 kHz |
Span | Full, 10, 20, 50, 100, 200, 500 MHz |
Input voltage range (TV) | 20 - 130 dBμV |
Input voltage range (SAT) | 30 - 130 dBμV |
Digital signal measurements | Bit Error Rate (BER), Carrier-to-Noise Ratio (CNR), Channel power, Modulation Error Ratio (MER), Noise margin, Wrong packets |
Analog signal measurements | Audio/Video level, Carrier-to-Noise Ratio (CNR), Level, Sync pulse, Video line |
Data logger | Y |
RF connector type | F |
---|---|
RF ports quantity | 1 |
Short circuit protection | Y |
---|---|
Reset button | Y |
Control type | Buttons, Rotary |
On Screen Display (OSD) | Y |
Built-in display | Y |
Display type | TFT |
Carrying case | Y |
---|---|
Power cord included | Y |
User guide | Y |
Power source type | Battery, DC |
---|---|
Low-Noise Block (LNB) power supply | 24V, 13V, 13V + 22kHz, 18V, 18V + 22kHz, 5V |
Input voltage | 20 V |
Charging time | 3 h |
Battery life | 2 h |
Unit of measure | dBm, dBmV, dBμV |
---|---|
RS-232 port | 1 |
Battery capacity | 30 Wh |
AC adapter bundled | Y |
