Processor
| Processor lithography |
45 nm |
| Thermal Design Power (TDP) |
80 W |
| Memory clock speeds supported by processor |
800 MHz |
| CPU multiplier (bus/core ratio) |
14 |
| Processor operating modes |
64-bit |
| Processor system type |
DP |
| Stepping |
D0 |
| Processor frequency |
1.86 GHz |
| Memory bandwidth supported by processor (max) |
19.2 GB/s |
| Maximum internal memory supported by processor |
144 GB |
| Processor cache type |
Smart Cache |
| Number of QPI links |
2 |
| Processor cache |
4 MB |
| Memory channels supported by processor |
Triple |
| Conflict Free processor |
N |
| FSB Parity |
N |
| Processor cores |
2 |
| Tcase |
76 °C |
| ECC supported by processor |
Y |
| Memory types supported by processor |
DDR3-SDRAM |
| Bus type |
QPI |
Processor special features
| Intel Fast Memory Access |
N |
| Intel Flex Memory Access |
N |
| Execute Disable Bit |
Y |
| Idle States |
Y |
| Thermal Monitoring Technologies |
N |
| Intel Trusted Execution Technology |
N |
| Physical Address Extension (PAE) |
40 bit |
| Intel Virtualization Technology (VT-x) |
Y |
| Processor package size |
42.5 mm |
| Processor ARK ID |
37092 |
| Processor code |
SLBEZ |
| Intel® Quick Sync Video Technology |
N |
| Intel® Insider™ |
N |
| Intel Hyper-Threading Technology |
N |
| Intel® Turbo Boost Technology |
N |
| Intel Enhanced Halt State |
Y |
| Intel vPro Technology |
N |
| Intel® Wireless Display (Intel® WiDi) |
N |
| Intel® Clear Video HD Technology (Intel® CVT HD) |
N |
| Intel Rapid Storage Technology |
N |
| Physical Address Extension (PAE) |
Y |
| Intel 64 |
Y |
| Intel Clear Video Technology |
N |
| Intel Dual Display Capable Technology |
N |
| CPU configuration (max) |
2 |
| Embedded options available |
N |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Y |
| Intel® Smart Cache |
Y |
| Intel® Anti-Theft Technology (Intel® AT) |
N |
| Intel® My WiFi Technology (Intel® MWT) |
N |
| Intel Clear Video Technology for MID |
N |
| Intel VT-x with Extended Page Tables (EPT) |
Y |
| Intel FDI Technology |
N |
| Enhanced Intel SpeedStep Technology |
Y |
| Intel Demand Based Switching |
Y |
Expansion slots
| PCI slots |
2 |
| PCI Express x16 slots |
1 |
Other features
| CD read speed |
40 x |
| Keyboard type |
Preferred Pro USB |
Memory
| Memory clock speed |
1066 MHz |
| Maximum internal memory |
12 GB |
| Internal memory type |
DDR3-SDRAM |
| Memory layout (slots x size) |
2 x 2 GB |
| Internal memory |
4 GB |
Storage
| Hard drive capacity |
250 GB |
| Card reader integrated |
Y |
| Hard drive interface |
Serial ATA |
| Hard drive speed |
7200 RPM |
| Compatible memory cards |
CF, MMC, SD, xD |
Ports & interfaces
| Line-in |
Y |
| Firewire (IEEE 1394) ports |
2 |
| Headphone outputs |
1 |
| Serial ports quantity |
1 |
| Microphone in |
Y |
| eSATA ports quantity |
1 |
Packaging content
| Display included |
N |
| Mouse included |
Y |
Optical drive
| Optical drive type |
DVD-RW |
Additionally
| InTru™ 3D Technology |
N |
| Intel AES New Instructions |
N |
| System bus data transfer rate |
4.8 GT/s |
| Ethernet LAN (RJ-45) ports quantity |
2 |
ThinkStation S20 (410528G), Intel Xeon E5502, 4GB DDR3 SDRAM, 250GB SATA HDD, DVD-RW, Windows XP Professional
Lenovo’s flagship performance machine, ThinkStation® workstation is exceptionally engineered for professional users of graphically and computationally intensive applications who require a level of performance unattainable with a standard desktop computer.
Powered by Intel® Xeon® processor technology ThinkStation workstation offers the professional-strength performance you need to do more, faster.
In developing the ultimate workstation, we took our legendary Think® product design and created two powerful, highly versatile models — the single-processor S Series workstations and the dual-processor D Series workstations.
A smarter workstation
ThinkStation workstations offer a user-centric, environmentally conscious design that boosts productivity and ultimately results in increased productivity for your business. Enjoy the following smart design features:
- Ergonomic removable top handle.
- Front-access media ports with illuminated icons and a recessed power button.
- Superior cable management.
- Premium side cover latch for easy access to internal components.
- Innovative thermal design with optimized fan placement, for a cooler, quieter, more reliable PC.
- All ThinkStation models are rack-mountable.
Security features:
- Boot sequence control.
- Boot without keyboard or mouse.
- Configuration password.
- Cover key lock.
- Diskette Boot inhibit.
- Security slot.
- Diskette I/O control.
- Hardfile I/O control.
- Padlock loop.
- Power on password.
- Serial port I/O control.
- U-Bolt anchoring feature.
- USB port individual disable.
