12V, 2A, 15 Satellit, 36dB
The Omnisat Seeker Wireless - A sophisticated, modern and innovative solution.
- Low Streamline Profile 17cm
-"Easy Adjust" Manual Skew Skew
- Twin LNB as standard - Designed for use with SKY+ receiver or free to air receiver with hard drive recording. Alternatively can be used to feed two separate receivers for independent working.
- All weather resistant construction
- Robust design solution utilising the latest advances in Computer Aided Design and Simulation software
- Complete with all installation cables and accessories - plug and play
WIRELESS CONTROL PANEL:
- Sleek modern styling
- Wireless or hard wired (included) as standard
- Backlit LCD display
- Stand alone or magnetic wall mount bracket (included)
- Simple to operate
- Clock/Temperature display
CONTROL BOX:
Sleek modern styling
- Compact size
- Future proof design - USB updates available for future satellites
- Universal Mount
- Intergral easy access fuse
Maxview's new Omnisat Seeker Wireless system has been designed with the user in mind. Simple to use, easy and flexible installation options with elegant and modern styling.
The ultimate in convience along with its latest features surpass any other automatic satellite system available on the market.
The unique wireless backlit LCD control panel features animated display icons feeding back antenna status to the user at all times. The wireless feature allows unlimited mounting options and easy installation, making unsightly cable runs and fixing problems a thing of the past.
The control box comes with unique versitile mounting brackets offering flexible installation options and can be coupled with any satellite receiver (not supplied) to give the ultimate package
- 12V operation
- Maximum 2A consumption during search
- Average search time: 30-60 seconds typical
- Automatic lowering ignition safety system
- High Quality 0.2db Universal Twin LNB
- Stores up to 15 satellites
- Pre-programmed with satellites including Astra 19.2E, Hotbird and Astra 28.2E
- Control Box allows any Satellite Receiver to be connected
- Full customer service back up and support
Programmed Satellites
Sat: 1 Name: ASTRA 19 Orbit: 19E
Sat: 2 Name: ASTRA 28 Orbit: 28E
Sat: 3 Name: HOTBIRD Orbit: 13E
Sat: 4 Name: ASTRA 23 Orbit: 23E
Sat: 5 Name: ATLBIRD3 Orbit: 5W
Sat: 6 Name: HELLAS 2 Orbit: 39E
Sat: 7 Name: EUBIRD 1 Orbit: 28E
Sat: 8 Name: ASTRA 5E Orbit: 5E
Sat: 9 Name: THOR Orbit: 1W
Sat: 10 Name: EURBIRD9 Orbit: 9E
MXL003/65 - OMNISAT SEEKER WIRELESS 65
- Antenna Unit Weight - 10kg
- 65cm Offset Aluminium Antenna
- 36dB gain
