Product types: Network receiver, AV receiver
Series: Onkyo TX-NR
Speaker configuration: A/B speaker terminals
Power per channel: 185 Watt
Technical specifications
Output power: 2.035 Watt
Output impedance: 6 Ohm
Constructions: Discrete power amplifiers, Digital Signal Processor (DSP), 4Ω speaker support, 32-bit D/A converter, with remote control
HDMI function: HDMI-CEC
HDMI version: HDMI 2.0
Playback formats: MP3, AAC, ALAC, FLAC, WMA Lossless
Playback media: DVD-Video, SACD
Connections
analog audio inputs: 7x LINE Inputs (RCA, Stereo), 1x MM Phono Input (RCA, Stereo)
analog audio output: 2x LINE Out (Cinch/RCA, Stereo)
digital audio inputs: 3x S/PDIF IN (Cinch/RCA coaxial), 2x S/PDIF IN (TOS-Link optical)
HDMI ports: 3x HDMI-Out, 7x HDMI-In
Video connections: 1x Component OUT, 2x Composite OUT, 2x Component IN, 3x Composite IN
Preamp outputs: 11.2 Surround (Cinch/RCA)
Front connection: iPod USB connection
gold-plated connections: yes
Audio
Audio functions: Multizone, LipSync, Direct Mode, Phase Control
Dolby formats: Dolby TrueHD, Dolby Atmos, Dolby ProLogic IIz
DTS Formats: DTS Neo:X, DTS HD Master Audio
THX Formats: THX Select 2 Plus
Number of listening zones: 3
Video
Supported Resolutions: UHD, Full HD
Video functions: Deep Color, 4K Pass-Through
3D-Ready: yes
Connectivity
Network functions: DLNA, App Control, Network Streaming
Wireless transmissions: Bluetooth, WLAN
Streaming services: Deezer, Aupeo, Pandora, TuneIn, Spotify, Internet radio
Universal Plug and Play (UPnP): yes
Functions
Comfort features: On-Screen Display (OSD)
Environmental properties: Display dimmer, auto power off
automatic measurement: yes
Calibration system: AccuEQ
Reception areas: FM (VHF), AM (MW)
RDS: yes
Number of station presets: 40
Power supply
Power consumption in operation: 1.105 Watt
Power consumption standby: 0,13 Watt
additional features
Weight: 22 kg
Housing property: Aluminum
Color: black
