Internal I/O
Chassis intrusion connector |
Y |
Number of chassis fan connectors |
6 |
Number of SATA connectors |
6 |
USB 2.0 connectors |
4 |
Memory
Supported DIMM module capacities |
1GB, 256MB, 2GB, 4GB, 512MB |
Memory channels |
Triple |
Non-ECC |
Y |
Supported memory clock speeds |
800, 1066, 1333 MHz |
ECC |
Y |
Number of DIMM slots |
6 |
Maximum internal memory |
24 GB |
Supported memory types |
DDR3-SDRAM |
Memory voltage |
1.5 V |
Back panel I/O ports
PS/2 ports quantity |
2 |
VGA (D-Sub) ports quantity |
1 |
Serial ports quantity |
1 |
Storage controllers
RAID support |
Y |
Hard drive interface |
Serial ATA II |
Design
Component for |
Server |
Motherboard form factor |
ATX |
Networking
Wi-Fi |
N |
Wake-on-LAN ready |
Y |
LAN controller |
Intel 82574L |
Ethernet interface type |
Gigabit Ethernet |
BIOS
ACPI version |
2.0 |
BIOS type |
EEPROM |
BIOS memory size |
32 MB |
Processor
Number of processors supported |
1 |
Intel Xeon series |
5500 |
Supported QPI |
4.8, 5.86, 6.4 GT/s |
Processor manufacturer |
Intel |
Processor number of cores supported |
4, 6 |
Performance
Motherboard southbridge |
Intel ICH10R |
Graphics
On-board graphics adapter memory |
16 MB |
Expansion slots
PCI slots |
1 |
PCI Express x16 (Gen 2.x) slots |
1 |
PCI Express x8 (Gen 2.x) slots |
1 |
Additionally
Chipset |
Intel X58 |
System bus data transfer rate |
6.4 GT/s |
Ethernet LAN connection |
Y |
Ethernet LAN (RJ-45) ports quantity |
2 |
X8STi (Standard Retail Pack) - Intel Core i7 / i7 Extreme Edition, Intel Nehalem (QPI up to 6.4 GT/s), Intel® X58 Express, 24GB DDR3 1333, 1066 & 800 ECC / non-ECC Un-Buffered DIMM, Dual Intel® 82574L Gigabit Ethernet, 6 x SATA (3.0Gbps) RAID 0, 1, 5, 10, 1 (x16) PCI-Express 2.0, 1 (x8) PCI-Express, 1x 32-bit PCI
